Capacity (Punch speed) |
(ALU/PVC) 20-60 cycles/min (ALU/ALU) 15-35 cycles/min |
|
Forming depth (max.) |
(ALU/PVC) 22 mm (ALU/ALU) 18 mm |
|
Adjustable distance of travel |
30-140 mm |
|
Air working pressure |
0.6-0.8 MPa |
|
Air consumption |
≥ 0.25 m3/min |
|
Power supply |
3-Phase 380V/50Hz, 8.5kW |
|
Machine dimensions (L*W*H) |
4500 * 760 * 1620 mm |
|
Machine weight |
1800 kg |
×
